Thorium Reactors and Nuclear Weapons Proliferation: “The Promise and Peril of Thorium”
Gordon Edwards in Hong Kong

There are many exaggerated claims made by promoters of thorium-based nuclear reactor technology as an alternative to the present generation of uranium-based reactors. One of those claims is that the use of thorium “fuel” instead of uranium fuel eliminates the threat of nuclear weapons proliferation because “thorium-fuelled reactors” do not produce plutonium as a byproduct. This claim is profoundly misleading.

By Gordon Edwards

Thorium is a naturally occurring radioactive element, but it is not a nuclear fuel, nor is it a nuclear explosive. The phrase “thorium fuel” is a misnomer. Thorium is not a fuel.

However, when thorium is bombarded with neutrons, it is transmuted into a type of uranium that does not exist in nature: uranium-233. This manufactured material, U-233, can subsequently be used as a nuclear fuel or as a nuclear explosive.

The article linked below is highly recommended. It provides a good discussion of the weapons proliferation risks associated with thorium-based nuclear reactor technologies.

http://wmdjunction.com/121031_thorium_reactors.htm

To better grasp the proliferation risk, some background on nuclear explosives is helpful.

Background on Nuclear Weapons:

All existing nuclear weapons use either uranium or plutonium as the primary nuclear explosive material. All nuclear fuels (fuels for nuclear reactors) are also based on either uranium or plutonium.

The story begins with naturally occurring uranium….

A. Uranium-235 — Uranium Enrichment

Uranium is the only naturally occurring material that can be utilized as a nuclear explosive.

However, not all kinds of uranium can be used to make nuclear weapons. One cannnot use natural uranium (the stuff that is mined), or low-enriched uranium (the stuff that is used as fuel in most commercial power reactors around the world) as a nuclear explosive. The problem with these materials is that there is too much uranium-238
(which is NOT a nuclear explosive) and too little uranium-235 (which IS a nuclear explosive).

Uranium enrichment is a technological process for increasing the concentration of uranium-235 by separating out and discarding much of the unwanted uranium-238. The end product of this separation process is called “enriched uranium” — uranium with a higher concentration of U-235 than that found in naturally occurring uranium. The discarded material — mostly uranium-238 — is called “depleted uranium” because it has even less uranium-235 per kilogram than is found in natural uranium ore deposits (0.7 percent).

Technically, any type of uranium in which the concentration of uranium-235 is 20 percent or more is called Highly Enriched Uranium (HEU). HEU of any kind can be used as a nuclear explosive material, if available in sufficient quantity. Nuclear weapons designers prefer HEU that is more than 90 percent enriched — i.e. more than 90 percent U-235. Such HEU is called “weapons-grade uranium”.

Any type of HEU is weapons-usable, even if it is not weapons-grade. Most commercial power reactors use only Low Enriched Uranium (LEU) as fuel; LEU cannot be used as a nuclear explosive due to the excessive amount of uranium-238 that it contains.

It is a slow, difficult, time-consuming process to enrich uranium — but once weapons-grade uranium is produced, it is rather easy to make a powerful atomic bomb with it. All that is needed is a “gun-type” mechanism to bring two pieces of HEU together very rapidly, by firing a uranium “bullet” into a uranium “target”. The Hiroshima bomb was made in this fashion. The gun-type mechanism is so simple there is no need to test it. It was guaranteed to work the very first time it was tried. As indeed it did….

If weapons-grade uranium falls into criminal hands, the construction of a powerful atomic bomb is a relatively simple matter. No testing is needed. That is why the civilian use of HEU is being phased out — it’s just too dangerous to allow this material to remain in commercial circulation.

B. Plutonium — Created from Uranium-238

Plutonium does not exist in nature; but it is created inside every reactor that uses natural uranium or low-enriched uranium as fuel. Some of the uranium-238 atoms in the fuel absorb stray neutrons, and those atoms are transmuted into plutonium atoms. It turns out that plutonium is a more powerful nuclear explosive than HEU. Plutonium is in fact more powerful than weapons-grade uranium.

Obtaining plutonium involves a chemical extraction process that requires dissolving highly radioactive “used nuclear fuel” in boiling nitric acid — not an easy task! This makes it difficult to divert the plutonium from civilian nuclear reactors into bombs, unless the plutonium has already been extracted ahead of time.

Once the plutonium has been separated from the rest of the radioactive garbage, it can be packaged and transported without detection fairly easily.

Using plutonium as a nuclear explosive does require a more elaborate bomb mechanism than the “gun-type” uranium bomb design. A sophisticated “implosion mechanism” is needed. That requires the simultaneous detonation of shaped charges (conventional explosives) surrounding a perfectly spherical ball of plutonium.

Such an implosion device is by no means simple; it requires painstaking engineering and careful testing. The Nagasaki bomb was made in this fashion. It was tested months ahead of time at Alamogordo, New Mexico.

All reactor-produced plutonium is weapons-usable, but nuclear weapons designers prefer to use plutonium with a very high percentage of plutonium-239 and a low percentage of plutonium-240. Such material is called “weapons grade plutonium”.

Although plutonium-240 is a nuclear explosive material, its presence complicates the job of the bomb-maker in two ways: (1) it makes the explosive material more difficult to handle because of higher levels of radio- activity and heat; (2) it makes the power of the nuclear explosion less predictable because it produces a lot of stray neutrons.

Despite these complications, any type of plutonium can be used to make reliable, highly effective nuclear weapons at all levels of technical sophistication.

See http://www.ccnr.org/Findings_plute.html

C. Uranium-233 — Created from Thorium-232

As previously remarked, naturally occurring thorium — thorium-232 — is the raw material from which a new kind of uranium — uranium-233 — can be created. All that’s needed is to bombard thorium-232 with neutrons. The easiest way to do that is to put the thorium inside a nuclear reactor, where neutrons are abundant. (Of course the reactor has to be fuelled by uranium or plutonium, otherwise there will be no neutrons.)

When a thorium-232 atom absorbs a stray neutron it is transmuted into an atom of protactinium-233, which then spontaneously transmutes itself into an atom of uranium-233 — a type of uranium not found in nature.

It turns out that uranium-233 is immediately weapons usable without the need for any kind of enrichment. It is a more powerful explosive than uranium-235, and — unlike plutonium — it can be used in a simple gun-type device, like the Hiroshima bomb.

Thus uranium-233 avoids one of the complications posed by the use of uranium-235 (the need for enrich- ment) as well as one of the complications associated with plutonium (the need for an implosion mechanism).

There is however another complication that arises. When thorium is placed inside a nuclear reactor, there is another type of uranium created called uranium-232. Although uranium-232 is also a nuclear explosive material, it is highly undesirable because it gives off an extremely powerful burst of gamma radiation — so powerful, in fact, that it can seriously damage electronic equipment.

The more uranium-233 is contaminated with uranium-232 the more difficult it is to use it as a nuclear explosive. But, as the article cited above (see link) points out, it is relatively easy to avoid this contamination problem. All that is required is to chemically separate the protactinium-233 at an early stage, remove it from the reactor environment, and then simply wait until it has almost all changed into uranium-233. In this way a stockpile of weapons-grade uranium-233 can be produced that is uncontaminated with uranium-232 and virtually trouble-free for making any type of nuclear weapon, including gun-type A-bombs.

The reason this works is due to the absence of neutrons outside the reactor environment. Uranium-232 is created only in the presence of neutrons, and outside the reactor there aren’t any neutrons — so no uranium-232 is being produced.

But protactinium-233 becomes uranium-233 spontaneously, without any need for neutrons. So by separating the protactinium-233 from the rest of the irradiated thorium, the potential bomb-maker gets lots of uranium-233, and virtually no uranium-232.

Gordon Edwards

****************

The Promise and Peril of Thorium
It’s time to evaluate claims that thorium-fueled reactors can reduce the proliferation risks of nuclear energy.
BY OLIVER TICKELL • 31 OCTOBER 2012 • UPDATED 5 NOVEMBER 2012
Update: An earlier version of this article misstated the half-life of protactinium-233.

Thorium, the “other” nuclear fuel, could be the basis of an entirely new nuclear industry that is clean, green, low-cost, and intrinsically resistant to the production of nuclear weapons. Such is the bold claim made by many of thorium’s committed band of advocates.[1]

The technology favored by thorium advocates differs from the current mainstream technology in two ways. First, it uses a thorium-uranium fuel cycle, instead of the dominant uranium-plutonium fuel cycle. Second, it uses the molten salt reactor (MSR) design, in which the nuclear fuel takes the form of high temperature (hence, molten) fluoride salts. Put the two together and you have the LFTR (Liquid Fluoride Thorium Reactor).

The MSR/LFTR technology was developed from the 1950s to the 1970s, mainly at the Oak Ridge National Laboratory in Tennessee. It all began under the Aircraft Nuclear Propulsion program, which sought to create a reactor suitable for powering US strategic bombers, enabling the aircraft to remain aloft for days or weeks at a time. Although the program was canceled in 1961 and no aircraft ever flew under nuclear power, the technology progressed under two subsequent programs, the MSRE (Molten Salt Reactor Experiment) and the MSBR (Molten Salt Breeder Reactor), until funding ceased in 1976.

At that time, the United States—and the rest of the world—decided to pursue exclusively the now dominant nuclear technologies: the uranium-plutonium fuel cycle and solid fuel reactor designs. These were chosen, say thorium advocates, because of their ability to produce plutonium for nuclear weapons, while MSR/LFTR designs were abandoned because they could not produce plutonium, and so failed to support the production of nuclear weapons.[2]

But following my own examination of the technology, I am forced to the very opposite conclusion: LFTRs could be used as highly efficient factories for very pure fissile material eminently suitable for bomb making. Furthermore, it is my belief—based on the facts set out here—that funding may have been cut because the widespread deployment of LFTRs would create an enormous proliferation hazard that is contrary to the US national interest.

Fissile Material Production 101

Key to this argument is that fact that it is really quite difficult to produce the fissile material for a nuclear bomb using established technologies. The first approach is to extract and enrich fissionable uranium-235 from natural uranium (converted to uranium hexafluoride) by way of cascades of centrifuges. The process requires significant amounts of energy and sophisticated technology, and amounts to a major industrial operation that is difficult to conceal.

The second approach is no less challenging, as it involves the “breeding” of fissionable plutonium-239 in uranium-fueled nuclear reactors, followed by the chemical separation of the plutonium that is formed in the fuel.

Adding to the difficulty, it is desirable to keep levels of the non-fissile isotope plutonium-240 (Pu-240) very low (under seven percent), since larger amounts increase radiation exposure rates for personnel assembling or handling nuclear weapons and can cause nuclear bombs to detonate prematurely, producing a lower than expected explosive yield or “fizzle.” Further, to achieve suitably low levels of Pu-240, reactors must run for a period of only weeks before the fuel is removed and reprocessed and the plutonium extracted—something that makes no sense at all where energy production is the objective.

The considerable difficulties involved in producing weapon-grade uranium and plutonium, and the relative ease with which efforts to that end may be detected, has effectively limited the “nuclear club” to a small number of nations, and has entirely excluded non-state actors. In general, a nuclear weapon state’s interest is to make it as hard as possible for others to join the club. If a technology were to emerge that would make the production of weapon-grade fissile material relatively inexpensive, easy, and yet difficult to detect, the United States would have good reason to suppress it.

Examining the Liquid Fluoride Thorium Reactor

But first, we need to understand how the LFTR works. It uses natural thorium-232 as its fuel. While thorium is not fissionable, it is fertile: irradiated by neutrons, it transmutes into a highly radioactive isotope, protactinium-233 (Pa-233), which in turn decays into the fissionable isotope uranium-233 (U-233), which constitutes the fuel.

U-233 is able to sustain a nuclear fission chain reaction just as U-235 does in a conventional reactor. The main difference is that some of the neutrons produced by the U-233 fission transmute the natural thorium into new U-233, thus maintaining the supply of uranium; indeed, it is key to the LFTR design that the U-233 is produced faster than it is consumed by fission. And of course, the whole process needs to be kicked off with neutrons from existing fissile material, for example U-235, Pu-239, or U-233.

This thorium fuel cycle can be carried out in a conventional solid fuel reactor, and indeed India is proposing to do precisely this in its forthcoming advanced heavy water reactors (construction of which will reportedly commence in 2014), intending to employ a fuel that includes thorium in addition to uranium and plutonium. But the fuel in any solid fuel reactor needs to be removed and reprocessed long before it is truly burnt up and no longer of use, otherwise some of these fissionable byproducts act as “neutron sinks,” degrading the “neutron economy”—the efficiency of the reactor—until the nuclear chain reaction grinds to a halt, or becomes difficult or impossible to restart once stopped.

This problem is solved in an MSR/LFTR by continuously reprocessing the molten salt fuel on-site, removing undesirable fission products. These include neutron sinks like xenon-135 and samarium-149, but also chemical contaminants like sulfur and oxygen, which can precipitate metal oxides from the molten salt. In this way, a batch of fuel can remain in a reactor for a considerable time, allowing a far more complete burn-up than could ever be supported in a conventional solid fuel reactor.

It is also desirable to remove the Pa-233 from the fuel in order to prevent the neutron bombardment from transmuting it into Pa-234. This is unwanted for three reasons: first, transmutation reduces the yield of U-233; secondly, it absorbs neutrons (reducing U-233 production); third, the Pa-234 decay produces uranium-232, whose decay series ends with the decay of the isotope thallium-208 (Tl-208), which emits an ultra-hard gamma ray with an energy of 2.6 million electron volts—enough to penetrate over a meter of concrete and damage electronics and control systems.

U-233 is the Key

This process was successfully carried out at Oak Ridge, where scientists developed means to remove the Pa-233 very efficiently using simple chemical reactions, even when the protactinium is present at the very low levels of 100 parts per trillion.[3] Once removed, the Pa-233 can simply be left aside until it decays into U-233. With a half-life of twenty-seven days, over 99.9 percent of the Pa-233 transmutes to U-233 over a period of about nine months. This U-233 can then be fed back into the reactor—or diverted in all or in part for another purpose, including bomb making.

To summarize, the protactinium removal has two important advantages for would-be bomb makers: very high purity U-233 is produced; and the U-233 contains very low levels of the undesirable U-232, whose daughter Tl-208 emits ultra-hard gamma rays capable of harming the health of handlers and machinists, damaging control electronics, and which can be detected by air- and even space-based sensors.

The world has but one experience of using U-233 in nuclear bombs. In 1955, the United States detonated a composite U-233/plutonium bomb in the Nevada desert as part of the Operation TEAPOT nuclear test series. The device detonated successfully, albeit with a lower than anticipated yield. With over half a century of nuclear weapons technology advances since then, there’s little doubt that U-233 bombs could be made highly viable, especially given the very high purities achievable, at least in principle, using LFTR technology with protactinium removal.

However, four major challenges complicate efforts to get LFTRs operational on a production scale:

Producing a reactor containment material that can withstand both intense radiation and high-temperature chemical assault from a wide spectrum of fission products and their daughters over a fifty year time scale;
Developing the continuous on-site reprocessing technology, using currently experimental pyroprocessing/electrorefining processes, so that it can operate reliably without accident or releases, also over a fifty year time scale;
Scaling up the experimental MSRE design used at Oak Ridge, with its 7 megawatt (MW) thermal power rating, into a production LFTR with a thermal output of 1,000 MW or more, capable of reliable continuous operation; and
Achieving all the above at modest cost, so that the resulting electricity can be sold in competitive energy markets.
Those embarking on any LFTR program would presumably hope and expect that these problems are ultimately soluble. It is also possible that a country—or countries—might initiate an LFTR program with a principal objective of producing a surplus of U-233 for making nuclear weapons, in which case the above considerations are likely to diminish in importance.

It is, of course, possible to build an LFTR without protactinium removal equipment; the resulting U-233 would be heavily contaminated with U-232, making it far from ideal bomb-making material. But protactinium removal could always be bolted on at a later stage, and the equipment itself concealed from nuclear inspectors, or its actual purpose obfuscated. Bearing in mind the intense radiation to which the on-site reprocessing equipment would be subject, and the high temperatures of 600 degrees centigrade or more, inspections would need to be conducted entirely using remote access/robotic methods, making accurate determination difficult.

But the key point here is that neither thorium, nor the LFTR, nor the uranium it produces, are intrinsically resistant to facilitating the proliferation of nuclear weapons. If LFTR designs are ultimately proven and become widespread, the selection of LFTRs as a means of producing fissile material would be an entirely rational choice for states either wishing to acquire nuclear weapons capabilities, or to increase their stock of nuclear weapons at much lower cost, and with much lower risk of detection, than using conventional technologies. As such, the technology itself would not prevent nuclear proliferation. That would only be possible with a frequent and rigorous inspection regime.

Oliver Tickell is an author, journalist, and campaigner specializing in environment, energy, and health issues. He is based in Oxford, England.

Notes

[1] See, for example, Richard Martin, “Uranium Is So Last Century—Enter Thorium, the New Green Nuke,” Wired, December 21, 2009, which characterizes the LFTR as “Proliferation potential: None.” See also the Flibe Energy website.
[2] Martin, “Uranium Is So Last Century—Enter Thorium, the New Green Nuke.”
[3] As detailed in C. J. Barton and H. H. Stone, “Removal of Protactinium From Molten Fluoride Breeder Blanket Mixtures,” Oak Ridge National Laboratory, ORNL-TM-1543, June 1, 1966.
